EM-series
Compact IoT RAIN RFID reader with Ethernet, USB, and Wi-Fi
The Identix EM-series 300 is a compact, high-performance IoT RAIN RFID reader equipped with four RF (SMA) ports for connecting external antennas. All antennas can operate simultaneously with independent radio configurations, providing flexibility for various application scenarios.
Compatible with a wide range of network and USB communication protocols, including MQTT, HTTP, and others, the DR-max enables rapid and efficient integration with diverse corporate systems and business applications.
Optionally, the EM-series can operate in “keyboard wedge” mode (USB HID keyboard emulation), facilitating integration with software compatible with barcode readers. Furthermore, the device can be configured to automatically decode RFID tags encoded in SGTIN-96, converting them directly to the EAN-13 barcode standard.
The EM-series also offers advanced and exclusive features for operation in POS environments, including intelligent data filtering algorithms that ensure fast, precise, and automatic capture of items identified with UHF RAIN RFID tags.
FEATURES
IoT RAIN RFID reader with Ethernet, Wi-Fi, and USB connectivity
UHF RAIN RFID reader/writer
Four RF ports for external antenna connection
2.4 GHz 802.11n Wi-Fi radio
Power supply via PoE or USB
COMMUNICATION
One PoE 802.11af Ethernet port
One USB port for data and power
Wi-Fi for data communication and remote management
GPIO: 1x GPI and 2x GPOs
COMMUNICATION PROTOCOLS
MQTT(s)
Sockets
Serial
HTTP(s) REST
WebSockets
Technical Specifications
UHF ISO18000-63 RFID reader/writer
Operating frequency: 865 MHz to 928 MHz
Maximum transmission power: +30 dBm
Reading speed: over 300 tags/s (M4)
Maximum sensitivity: -73 dBm (M8)
Four RF ports (SMA-F) for external antenna connection
Data communication via Ethernet, Wi-Fi, or USB
Communication protocols: MQTT(s), sockets, WebSockets, and HTTP(s)
USB: keyboard emulation (HID), RAW ASCII
General
One Ethernet PoE 802.11af port (15W)
Bluetooth 5 radio and 2.4 GHz 802.11n Wi-Fi with a maximum speed of 150 Mbps
Integrated RGB LED and buzzer for feedback signaling
One USB port for communication and power supply
Maximum power consumption of 10 W when operating at +30 dBm output power
E-fuse: electronic fuse for overvoltage and overcurrent protection
Integrated sensors for continuous voltage and current monitoring
One GPI and two opto-isolated GPOs
Weight: 250 g
Dimensions: 145 x 85 x 25 mm
Environmental protection rating IP64
Operating temperature: -20 °C to +65 °C
Certifications: Anatel and FCC
