EZ series
High-performance IoT RAIN RFID reader
Identix EZ-series is a family of IoT UHF RAIN RFID readers specially designed for use in high-performance industrial applications
Ethernet PoE and Wi-Fi connectivity, combined with communication protocols such as MQTT and HTTP, enables rapid and seamless integration with various business applications
Advanced features such as DRM (Dense Reader Mode) and SJC (Self Jamming Cancelation) ensure efficient and reliable RFID tag reading under the most challenging conditions
Additionally, when used with RFID tags equipped with the Impinj M800 chip, they deliver a significant increase in read performance, reducing inventory time for tags of interest (TOI) by up to 90%, thanks to the features of the Impinj GEN2X Toolbox
They also incorporate a high-power integrated GPIO module for connecting sensors and actuators, eliminating the need for additional devices and reducing the overall installation cost of the RFID reading system
The EZ-series piglets can be optionally equipped with height sensors and an accelerometer, specifically for deployment on forklifts and other load-handling equipment, enabling automated recording of storage and retrieval of items identified with RFID tags.
FEATURES
IoT UHF RAIN RFID reader/writer
Connectivity via Ethernet, Wi-Fi and BLE
Power supply by DC source or PoE
PERFORMANCE
Ez700
Read rate: 1000 tags/s
Sensitivity: -89 dBm
Ez500
Read rate: 700 tags/s
Sensitivity: -81 dBm
COMMUNICATION
One PoE-enabled RJ45 Ethernet port at 100 Mbps
Wi-Fi 802.11n at 150 Mbps
Two opto-isolated GPI ports
Four GPO outputs with configurable output voltage
Built-in buzzer and RGB LEDs for signaling
One USB port
One RS232C serial port
COMMUNICATION PROTOCOLS
MQTT(s)
Sockets
HTTP(s) REST
WebSockets
Technical Specifications
UHF RAIN RFID reader ISO18006-C with four RF ports (TNC)
Operating frequency: 865–928 MHz
Maximum transmission power: +31dBm (max)
Sensitivity: -81dBm (max)
A 100 Mbps PoE Ethernet port (802.3af/at)
Wi-Fi 802.11n and BLE integrated into a single 2.4 GHz radio
Integrated GPIOs
Two opto-isolated inputs (GPIs)
Four outputs (GPOs) with software-configurable output voltage
A 110 dB buzzer and two high brightness RGB LEDs for signaling
One USB port
One RS232C serial port
DC power supply: +9 VDC to +28 VDC
Dimensions: 152 × 125 × 34 mm
Operating temperature: -20 to +50 °C Humidity: 5% to 95% non-condensing
Approximate weight: 350 g
Protection rating: IP54
Certifications: FCC and Anatel
